APEX Mini combines thermal imaging,High-precision laser ranging, and direct-view screen operation in a lightweight platform designed for portability, simplicity, and dependable field performance.
Smaller in size. Ready for the field.
The APEX Mini Thermal Riflescope is built for users who want thermal capability in a lighter, more accessible format. With a 384 × 288 / 12μm thermal sensor, 35mm F1.0 lens, up to 1800m detection range, and a built-in laser rangefinder, it delivers the core performance needed for confident observation and practical shooting support. Compact, intuitive, and field-ready, APEX Mini is designed for users who value mobility without sacrificing essential functionality.
APEXCOR’s proprietary AI-powered image processing algorithm adapts intelligently to diverse scenarios and environments, delivering stable and consistent image quality without manual intervention. Whether used for outdoor hunting, under strong light, backlighting, or changing conditions, it dynamically optimizes every scene to ensure complete, vivid, and true-to-life visuals. By effectively reducing environmental temperature noise, the algorithm enhances contrast, preserves fine details, and provides clearer, more reliable images in every shot.
With APEXCOR’s breakthrough NETD of less than 15mK, the detector reaches a new level of thermal sensitivity, capturing even the slightest temperature differences with stable performance. This ultra-low NETD enables exceptionally clear, smooth, and detailed thermal imagery, enhancing perception of the surrounding environment. Hunters can easily distinguish an animal’s outline, anatomy, and unique behavioral traits, supporting precise trophy recognition and helping them make more confident and accurate hunting decisions in the field.
With a high 50Hz refresh rate, the detector delivers smoother, more fluid thermal imagery with faster response times. This upgrade ensures clearer visuals and more stable tracking when observing fast-moving prey. Even during rapid movement, targets remain continuous, natural, and detailed, helping hunters maintain focus and follow every motion with ease.
Powered by APEXCOR’s super-resolution algorithm, the device delivers enhanced clarity during digital magnification, maintaining sharp and ultra-detailed images without quality loss. Combining base magnification with continuous digital zoom up to 4x, the algorithm sharpens key details such as outlines, subtle movements, and size differences, helping users identify targets more quickly and precisely.
APEXCOR’s algorithm intelligently reduces shutter frequency by continuously learning from different grey-level backgrounds, minimizing image freezing without compromising image quality. This dynamic process adapts to changing environments, reducing calibration pauses and ensuring stable, consistent visuals. With fewer interruptions and smoother observation, users can stay focused and never miss a critical moment in the field.
The APEX Series features an integrated LRF module with true optical axis alignment, delivering laser range-finding up to 1,200m with ±1m accuracy. By providing precise distance data for ballistic calculation, it helps hunters make more accurate aiming adjustments and achieve confident shots in demanding hunting scenarios.
The APEX Compact Series features an integrated built-in LRF module with true optical axis alignment, delivering laser range-finding up to 1,200m with ±1m accuracy. It ensures precise distance measurement for hunters while preserving a clean, streamlined design.
The APEX Mini Series features a durable magnesium-aluminum alloy housing and rugged internal components, delivering shock resistance up to 1000g/0.4ms. With IP67 dust and water resistance, it ensures reliable performance, accuracy, and durability in demanding field conditions.
The APEX Mini Series is designed for long-range precision shooting, supporting advanced ballistic calculation to compute the suggested impact point based on bullet drag model, weight, distance, wind speed, wind direction, and other key parameters. When bullet data is unknown, users can use Ballistic Calibration by shooting targets at different distances and recording impact points to generate a fitted trajectory curve. After range measurement, the system provides accurate aiming references based on the calculated or calibrated ballistic path. Users can also customize the color and style of the suggested impact point for clearer, more intuitive targeting.
The APEX mini series offers 7 reticle styles and 6 color options, allowing users to freely customize their aiming display for different preferences and scenarios, delivering a more convenient, intuitive, and user-friendly shooting experience.
| Item category | APEX Mini M335L |
| Thermal Module | |
| Image Sensor | UFPA (VOx) |
| Resolution | 384×288 |
| Pixel Pitch | 12µm |
| Frame Rate | 50Hz |
| NETD | ≤18mk |
| Spectral Range | 8-14µm |
| Optical Parameter | |
| Focal length / Aperture | 35mm; F1.0 |
| Field of View | 7.5°×5.6° |
| Base Magnification | 1.5X |
| Focusing Mode | Focus Ring |
| Eye Relief | - |
| Exit Pupil | - |
| Diopter | - |
| Detection Range | 1800m (Human; 3pixels) |
| Recognition Range | 450m (Human; 12pixels) |
| Image Display | |
| Screen | AMOLED, 0.39 inch |
| Resolution | 1024×768 |
| Screen Brightness Adjustment | Support |
| Brightness Adjustment | Support |
| Contrast Adjustment | Support |
| Image Enhancement | Support |
| Scene Mode | City;Plain;Forest |
| Display Mode | - |
| Color Palette | White Hot/Black Hot/Red Hot/Fusion/Golden Hot etc. |
| Digital Zoom | 1× to 4× step by 0.2× |
| Power Supply | |
| Battery type & Number | 1 replaceable 18650 Lithium battery |
| External Power Supply | DC 5V (USB Type-C) |
| Battery Operating Time | ≥7.5h (25℃) |
| System | |
| Record Video | Support |
| Capture Snapshot | Support |
| Audio Recording | Support |
| Local Album | Support |
| Recoil Activation Recording | Support |
| Picture in Picture | Support |
| Hot Track | Support |
| Zeroing Adaptation Mode | Support |
| Screen Adaptation | - |
| Standby Mode | Support |
| Ballistic Calculation | Support |
| Ballistic Calibration | Support |
| Distance Measurement | Support |
| Zeroing Profiles | 10 |
| Reticle Pattern | 8 |
| Reticle Pattern | 6 |
| Aim Point Type | 3 |
| Aim Point Colour | 6 |
| BC Aim Point Type | 5 |
| BC Aim Point Colour | 4 |
| Ranging Cursor Type | 3 |
| Ranging Cursor Colour | 3 |
| Peripheral | |
| Electronic Compass | Support |
| Attitude Sensor | Support |
| WIFI /APP | Support; 2.4G |
| Storage | Built-in EMMC (32GB) |
| Laser Rangefinder | 905nm;Class 1 Laser Safety |
| Ranging Distance & Accuracy | 1.2 Km*; ±1m |
| General | |
| Data Transmission Interface | USB (Type-C) |
| Protection Level | IP67 |
| Operating Temperature | -20°C to +50°C |
| Max. Recoil | 1000g/0.4ms |
| Weight(without battery) | ≤455g |
| Dimension | 134×87×86(mm) |
* When measuring large, highly reflective targets (such as buildings with a reflectivity of 70%) in conditions without direct sunlight, the laser ranging module can achieve this range.
